10LD6 Vacuum Tube – Beam Power Pentode for TV Horizontal-Deflection Output

The 10LD6 is a beam power pentode from the family of TV horizontal-deflection output tubes (alongside the 6DQ6, 6JB6, and 6KD6), built to switch the horizontal yoke coils with a sawtooth drive waveform.

• Tube type: Beam power pentode
• Heater: ~10V AC (series-string TV tube family)
• Typical use: Horizontal-deflection output stage in television receivers

Part of the same functional family as the 6DQ6/6JB6/6KD6/6CD6 horizontal output tubes.
