117Z6 Vacuum Tube – Full-Wave / Voltage-Doubler Rectifier for AC/DC Radios

The 117Z6 packages two separate rectifier sections behind a common 117V heater, letting it be wired as a full-wave rectifier, half-wave rectifier, or voltage doubler depending on the circuit.

• Tube type: Dual-section rectifier
• Heater: 117V AC/DC, no transformer required
• Typical use: Flexible rectifier stage in transformerless AC/DC radios and portable receivers

Also cataloged as 117Z7 in its GT-envelope form.
